| Output DC parameter Power MOSFET |
Safe continuous rating id at 550C
|
Amp |
05 |
03 |
Drain-to-source break down voltage
Vdss (BR) |
VDC |
200 |
500 |
Continuous Drain current id
@Tc=250C |
Amp |
18 |
8 |
Static drain-to-source On
resistance rDS (ON) |
Ohm |
0.18 |
0.85 |
| Power dissipation Pd@ TC - 250C |
W |
125 |
125 |
Repetitive or non repetitive
drain current |
Amp |
70 |
30 |
| Peck diode recovery dv/dt |
V/ns |
4 |
4 |
Drain-to-source leakage current
Idss |
mA |
10 |
10 |
Maximum junction temperature
Tj (max) |
0C |
150 |
150 |
Thermal resistance junction to
case Rthjc |
0CW |
1 |
1 |
| Turn ON delay time Td (ON) |
S |
300 |
300 |
| Turn OFF delay time Td (OFF) |
S |
300 |
300 |
Input-Output body isolation
voltage |
KVA |
4 |
4 |
| Duty Cycle (100%) |
|
1 |
1 |
ON Voltage drop less than at
rated current |
Vds |
1.7 |
3.5 |
| Square wave output |
Hz |
400Hz |
|
